Steel Ute Tray Plans - Dual Cab 4
Steel Ute Tray Plans - Space Cab 1
Steel Ute Tray Plans - Space Cab 2
Steel Ute Tray Plans - Space Cab 3
Steel Ute Tray Plans - Space Cab 4
Steel Ute Tray Plans - Single Cab 1
Steel Ute Tray Plans - Single Cab 2
Steel Ute Tray Plans - Single Cab 3
Steel Ute Tray Plans - Single Cab 4
Steel Ute Tray Plans - Single Cab 5
Steel Ute Tray Plans - Dual Cab 1
Steel Ute Tray Plans - Dual Cab 2
Steel Ute Tray Plans - Dual Cab 3
Steel Ute Tray Plans - Dual Cab 4
Steel Ute Tray Plans - Space Cab 1
Steel Ute Tray Plans - Space Cab 2
Steel Ute Tray Plans - Space Cab 3
Steel Ute Tray Plans - Space Cab 4
Steel Ute Tray Plans - Single Cab 1
Steel Ute Tray Plans - Single Cab 2
Steel Ute Tray Plans - Single Cab 3
Steel Ute Tray Plans - Single Cab 4
Steel Ute Tray Plans - Single Cab 5

Steel Ute Tray Plans

14 reviews
  • Easily adjustable to suit your vehicle
  • Heavy duty construction
  • Side gates
  • Wheel guards
  • Instant digital download
Skill Level: Basic

$99.00

Specifications

Tray Size/s

  • Dual cab: 1.85m L x 1.85m W (6.1ft x 6.1ft)
  • Space cab: 2.15m L x 1.85m W (7.1ft x 6.1ft)
  • Single cab: 2.45m L x 1.85m W (8ft x 6.1ft)

Side Height

0.25m (0.8ft)

Tray Weight

~200kg (441lbs)
steel tray plans pdf example

Description - Steel Ute Tray Plans

Our steel tray plans are basic in design which allows for unlimited customisation for your needs. These plans will fit most ute style vehicles on the market, although you may need to make alterations to fit your specific vehicle. You will receive a complete set of workshop drawings, including tray sides and wheel guards.

What's Included:

  • Detailed Workshop Drawings (PDF document)
  • Complete Cutting and Part lists
  • DXF Files*
  • Information Booklet

* CAD files not included.
* All drawings and dimensions are in metric.
* DXF files are only included for sheet metal/plate parts.
* Plans may vary from display images.

Reviews

4.8
Based on 14 reviews
5 star
79
79%
4 star
21
21%
3 star
0%
2 star
0%
1 star
0%
1-2 of 14 reviews
  1. JR
    James R. au
    Reviewer
    Steel Ute Tray PlansSteel Ute Tray Plans

    Great detailed drawing easy to follow Thank you

    • F
      Fabplans
      Store manager

      Cheers James

Why Choose Fabplans

Fabplans are designed to work with commonly found material sizes and off-the-shelf parts. To make the build process even easier, we have compiled all the parts (Part List) and materials (Cutting List) so that you know exactly what is needed and can effectively cost your project.

Consider this, if you accidentally buy just one extra length of steel or make a single mistake (which is far less likely when you have detailed plans), the cost of that error could easily exceed the price of our plans.

Our plans are packed with research, hands-on experience, and practical know-how.
